INGENIA IG2T Cod. 420120238 REV. 1.1
4. INSTALLATION EXAMPLES
• To use 2 stacked speakers, you need the optional LP-IG accessory. For further information,
please refer to the instructions of this accessory.
• Always check that the handles, allowing the infra-red communication, are not obstructed;
never cover them and remove any dust or dirt deposits.
• No installation other than that shown here is allowed.
INSTALLATION ON STAND
INSTALLATION ON SUBWOOFER WITH POLE
INSTALLATION ON SUBWOOFER
1 INGENIA IG2T can be installed on an optional standard tripod stand, with a pole
having a diameter of 35 mm. The maximum permissible height between the base
of the speaker and the oor is 150 cm.
It is possible to use a single speaker mounted on 35 mm diameter pole. Additional
mechanical xing, or xing with straps, is required to properly secure the
installation. The maximum permissible height between the base of the speaker
and the oor is 150 cm. Once the installation is completed, follow the subwoofer
conguration instructions in the SUBWOOFER MATCHING section.
ATTENTION!
• Use an appropriately sized stand with the central foot forward to
ensure proper stability.
• When “Stacked” on a stand, the INGENIA IG2T cannot be
mounted in the conguration with 2 speakers stacked, but only
in a single speaker conguration, for safety reasons.
Using the GSA-IG accessory during the installation, you can use the speakers (1 o
2) mounted on subwoofer. This allows to get an extremely compact system, with
great output power over the whole range of sound frequencies, installed on the
ground. Additional mechanical xing, or xing with straps, is required to properly
secure the installation. Once the installation is completed, follow the subwoofer
conguration instructions in the SUBWOOFER MATCHING section.
