Rear panel operations
Time
Output Signal
Input Signal
Output Signal
Intelligent Predictive Limiting™
Release Time
Attack Time
}
2 dB Typically
Figure 3: Protective Action of the PeakStopPlus™ Limiter
Stereo Couple Switch - These switches change the 1046 from four independent compressors into two stereo
compressors. In stereo mode, Channel 1 is the master and Channel 2 is its slave, and Channel 3 is the master
andchannel4isitsslave.EachoftheChannel2and4controlsandswitchfunctionswillbeoverridenand
controlledbytheChannel1and3controlsandswitches,respectively,exceptfortheI/OMeterandBypass
switches.Also,Channel2’sand4’sCompressorThreshold,andPeakStopPlus™Thresholdmeterswillbedisabled,
whiletheseslavechannels’GainReductionmeterswillindicatetheamountofgainreductionoccurring,as
ontheirmasters’GainReductionMeters.All4channelshaveequalprecedenceasfarassignalprocessingis
concerned.Thedbx1046usesTrueRMSPowerSumming™,anextremelyaccurateandmusicalwaytocombine
detectoroutputsinastereosituation.Theswitchwilllighttoindicatethatthe1046isintheStereoCouple
mode.
Rear Panel Operations
Rear Panel
FUSE: T 300mA L 250V
30
AC Power Receptacle-UsethesuppliedACcabletoconnecttheunittoACpower.TheACreceptacleincludes
anintegralpull-outfusedrawerwhichcontainstwofuses;theactivefuseandasparefuse.Replacethefuse
with the same type and rating only.as indicated on the rear panel.
Audio Inputs-EachchannelfeaturesbothXLRand1/4”TRSelectronicallybalancedinputs.Inputsmaybeused
inabalancedorunbalancedconfiguration.NotethattheXLRand1/4’inputsmayNOTbeusedsimultaneously.
