Specifications
Input
Connectors: Female XLR and 1/4” TRS (Pin 2 and tip hot)
Type: Electronically balanced/unbalanced, RF filtered
Impedance: Balanced > 50 kΩ, unbalanced >25 kΩ
Max Input Level: > +24 dBu balanced or unbalanced
CMRR: 40 dB; Typically >55 dB at 1 kHz
Output
Connectors: Male XLR and 1/4” TRS (Pin 2 and tip hot)
Type: Servo-balanced/unbalanced, RF filtered
Impedance: Balanced 60Ω, unbalanced 30Ω
Max Output Level: > +21 dBu, >+20 dBm balanced/unbalanced
System Performance
Bandwidth: 20 Hz to 20 kHz, +0/-0.5 dB
Frequency Response: 0.35 Hz to 200 kHz, +0/-3 dB
Noise: < -94 dBu, unweighted, 22 kHz measurement bandwidth
Dynamic Range: > 118 dB, unweighted
THD+Noise: 0.009% typical at +4 dBu, 1 kHz unity gain
0.09% typical at +20 dBu, 1 kHz, unity gain
< 0.1% any amount of compression up to 40 dB, 1 kHz
IMD: < 0.1% SMPTE
Interchannel Crosstalk: < -85 dB, 20 Hz to 20 kHz
VCA: dbx V2™
Stereo Coupling: True RMS Power Summing
Compressor
Threshold Range: -40 dBu to +20 dBu
Ratio: 1:1 to ∞:1
Threshold Characteristic: Selectable OverEasy® or hard knee
Attack/Release Characteristic: AutoDynamic™
Attack Time: Program-dependent, typically 15ms for 10 dB, 5 ms for 20 dB, 3 ms for 30 dB
Release Time: Program-dependent, typically 125 dB/sec
Output Gain: -20 to +20 dB
Limiter
Threshold Range: +4 dBu to +22 dBu (off)
Ratio: ∞:1
Limiter Type: PeakStopPlus™ two-stage limiter
Stage 1: Instantaneous Transient Clamp™
Attack Time: Zero
Release Time: Zero
Stage 2: Intelligent Predictive Limiting™
Attack Time: Program-dependent, typically <5 msec
Release Time: Program-dependent, typically 22 dB/sec
Function Switches
OverEasy®: Activates the OverEasy® compression function.
I/O Meter: Switches between monitoring input and output levels on the Input/Output Level meter.
Bypass: Activates the direct input-to-output hard-wire bypass.
Operating Level (rear panel): Switches the nominal operating level between -10 dBV and +4 dBu simultaneously for both input and output levels.
Stereo Couple: Couples channels in stereo pairs. Channels One and Three become the master channels.
Indicators
Gain Reduction 8 segment LED bar graph at 1, 3, 6, 10, 15, 20, 25, and 30 dB
Input/Ouptut Level 8-segment LED bar graph at -24, -18, -12, -6, 0, +6, +12, and +18 dBu
Limiter Threshold: 1 LED to indicate PeakStopPlus™ limiting
Function Switches: LED indicator for each front-panel switch
