Dcm MC-HD200 - Page 34

33
AWBSens:The white balance sensitivity,
Optional items:Low,Normal,High
Hue:Automatic white balance is tonal,Optional
items:-7 ~ +7, Default 0（Effective only in Manual
mode）
4. IMAGE
Move the cursor to the Image item in the main
menu and press [HOME] button,IMAGE menu
appears,as shown in the following figure.
Brightness:Brightness adjustment.Optional
items:-5 ~ +5
Contrast:Contrast adjustment. Optional items: -5
~ +5
Sharpness:Sharpness adjustment. Optional items:
0 ~ 15
B&W-Mode:Black and white mode switch.
Optional items: On, Off
Flip-H:Image flipped horizontally.Optional
items: On,Off
Flip-V:Image Flip Vertical.Optional items:On,
Off
Gamma:Gamma adjust,Optional items:0.31 ~
0.83
5.P/T/Z
SpeedByZ:The depth of field scale switch,
P/T/Z
SpeedByZ On
L/R Set STD
AF-Zone Center
AF-Sense Low
Select Item
Change Value
[Menu] Back
Brightness 0
Contrast 0
Sharpness 8
B&W-Mode Off
Flip-H Off
Flip-V Off
Gamma 0.71
Select Item
Change Value
[Menu] Back
