35
menu and press [HOME] button,SETUP menu
appears,as shown in the following figure.
Language:menu language,Optional items:EN,
Chinese
ColorSys:Set the DVI system,color in the analog
signal,Optional items:YPbPr,RGB（ Only effective
under 720 P60/1080P60）
HDMIMode:Set the HDMI output signal
mode,Optional items: On,Off
Protocol:Control protocol type.Optional items:
VISCA,P-D,P-P
Address:protocol address,To be decided
according to the agreement,can be set up under the
VISCA items:1 ~ 7,P - P and P- D can be set up:0 ~
254
AddrFix:If I can change through the serial port
of infrared switch,Optional items:On,Off(When set to
On,cannot address via a serial port to modify the
camera)
Net Mode:The net mode of camera,Optional
items:Serial,Paral
Baudrate:Serial port baud rate.Optional items:
2400, 4800, 9600
8. RESTORE DEFAULT
Move the cursor to the Restore Default item in
the main menu and press [HOME] button,RESTORE
DEFAULT menu appears,as shown in the following
figure.
SETUP
Language EN
ColorSys YPbPr
HDMIMode Off
Protocol VISCA
Address 1
AddrFix Off
Net Mode Serial
Baudrate 9600
Select Item
Change Value
[Menu] Back
