REF. NO. PART NO. DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “
∆∆
∆∆
∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
∗∆
∗∆
∗
ELECTRIC PARTS
1- 1 19133 High voltage capacitor 1 AQ
1- 2 19099 High voltage rectifier assembly 1 AM
1- 3 19130 Oven lamp socket 1 AE
1- 4 19134 Oven lamp 1 AE
1- 5 19136 Fan motor 1 AR
1- 6 19127 Fuse holder 1 AD
1- 7 19098
Monitor switch (V-16G-2C25) and fuse assembly (20A 250V AC)
1AF
1- 8 19131
Secondary interlock switch and door sensing switch (V-5230Q)
2AE
1- 9 19128 Magnetron temperature fuse 150½C 1 AE
1-10 19129 Cavity temperature fuse 150½C 1 AF
1-11 19138-01 Magnetron 1 BE
1-11 19138-02 Magnetron (Interchangeable) 1 BE
1-12 19135 Turntable motor 1 AK
1-13 19137 Power transformer 1 BA
1-14 19094 Power supply cord 1 AM
1-15 19097 AH sensor 1 AW
CABINET PARTS
2- 1 19106 Base plate 1 BC
2- 2 19107 Foot 4 AB
2- 3 19104 Outer case cabinet 1 BC
CONTROL PANEL PARTS
3- 1 19144 Control panel assembly 1 BM
3- 2 19100 Control panel frame assembly 1 AX
3- 3 19102 Key unit 1 AS
3- 4 19108 Open button 1 AE
3- 5 19115 Open button spring 1 AA
3- 6 19143-03 Screw; 3mm x 10mm 3 AA
OVEN PARTS
4- 1 19110 H.V. Capacitor band 1 AB
4- 2 19109 Chassis support 1 AE
4- 3 19124 Latch hook 1 AF
4- 4 19113 Switch lever 1 AD
4- 5 19121 Magnetron duct 1 AG
4- 6 19116 Fan blade 1 AC
4- 7 19120 Fan duct 1 AC
4- 8 19118 Waveguide cover 1 AV
4- 9 19125 Turntable motor packing 1 AA
4-10 19122 Sensor duct 1 AG
4-11 19119 Cushion 1 AC
DOOR PARTS
5 -1 19095 Door frame assembly 1 AK
5-1-1 19111 Latch head 1 AE
5-1-2 19114 Latch spring 1 AB
5 -2 19096 Door panel 1 AX
5- 3 19126 Sealer film 1 AD
5- 4 19105 Choke cover 1 AG
