3. Ventilation and installation
To ensure adequate ventilation for your refrigerator and its correct operation see
recommended cabinetry dimensions below.
The appliance is intended to be placed against a wall with a free distance not exceeding
3” (75 mm).
RF195A
Cabinetry dimensions (including minimum air clearances) inches mm
A
inside height 70 / 1791
Flush with refrigerator chassis – full door rotation
B
inside width 36 915
C
inside depth 24 / 622
Flush with refrigerator door – full door rotation
D
inside width 46 / 1175
E
inside depth flush to flat door 27 / 696
Flush with refrigerator door – 90° door rotation
F
inside width 44 / 1130
G
inside depth flush to flat door 27 / 696
Minimum clearances
H
side clearance / 5
I
side clearance – hinge side flush with door – 90° rotation 3 / 90
J
side clearance – hinge side flush with door – full rotation 5 / 135
K
rear clearance (incl. rear compartment cover) 1 25
L
top clearance 1 / 44.5
M
vent 2 50
N
door clearance – hinge side flush with chassis – full rotation 16 / 415
O
door clearance – hinge side flush door – full rotation 11 / 285
Note: an integration surround kit is available through your local DCS dealer or Authorized Service
Agency to trim a 72” high x 36” wide cabinetry opening.
This requires no rear cabinet venting (M).
