PARTS LIST:
ITEM # PART # DESCRIPTION
1 12112 T OP HALF GRATE
1A 15002-32 GRATE LEVELING SCREW
2 12131 SIMMER CAP
3 12130PC BURNER PORT RING
4A 12104 SIMMER TUBE CAP
4B 12102 SIMMER BURNER CAP
4C 12101 SIMMER BURNER RING
5 12105 SIMMER BURNER BOWL
6 12093 ELECTRODE
7 12094 ELECTRODE SPRING CLIP
8 15001-09 BURNER BASE SCREWS
9 15020-29 VENTURI BOLT
10 14000 VENTURI GASKET
11 12113 MAIN VENTURI, REAR
12 12115 SIMMER VENTURI, REAR
13 15004-04 VENTURI NUT
14 13236 SPARK MODULE
15 12116 SIMMER VENTURI, FRONT
16 12114 MAIN VENTURI, FRONT
17 16006 TERMINAL BLOCK
18 15109 VA LVE SCREW / PLUG / WASHER
19 16075 POWER CORD - RANGES
16005 POWER CORD - COOKTOPS
20 13071 SPARK SWITCH / SIMMER, STD. BURNER
21 14006-PL BEZEL
22 14125 SIMMER BURNER KNOB
23 14124 SIMMER BLOCK O-RING
24 13070 SIMMER BLOCK
13005-80 SIMMER ORIFICE HOOD, LP GAS
13005-80 SIMMER ORIFICE HOOD, NATURAL GAS
25 13005-50 ORIFICE HOOD, LP GAS
13005-50 ORIFICE HOOD, NATURAL GAS
26 13069 SIMMER VALVE
27 12100 SIMMER BURNER BASE
28 18170 OVEN FEED ADAPTER
29 15002-02 SCREW
30 90129 BURNER HANGER
31 90085 GRATE SUPPORT (L)
32 90084 GRATE SUPPORT (R)
33 16131-01 ELECTRODE WIRE
11
OPEN TOP BURNER ASSEMBLY
