14
PARTS LIST:
ITEM # PART # DESCRIPTION
1 90254 GRIDDLE COVER
2 90140 GRIDDLE FLUE COVER
3 90192-01 GRIDDLE / GRILL FRONT TRIM
4 90192-02 GRIDDLE FRONT TRIM
5 90133 GRIDDLE PLATE ASSEMBLY
6 12005-1 GRIDDLE BURNER
7 16009-1 IGNITER
8 90141 GRIDDLE BAFFLE
9 30313-3 DRIP PAN LINER
10 90045-01 GRIDDLE TUBING
11 13073 THERMAL VALVE
12 18017 ELBOW ASSEMBLY
13 18166 MANIFOLD ADAPTER
14 18165 PIPE PLUG
15 15109 VA LVE SCREW / PLUG / WASHER
16 16046-1 INDICATOR LIGHT
17 13010-3 GRIDDLE THERMOSTAT
18 14006-PL BEZEL
19 14129 GRIDDLE THERMOSTAT KNOB
20 16077 FIBERGLASS SLEEVE
21 16006 TERMINAL BLOCK
22 16075 POWER CORD-RANGES
16005 POWER CORD-COOKTOPS
23 16077 FIBERGLASS SLEEVE
24 13005-48 ORIFICE HOOD-NATURAL GAS (#48 DMS)
[ORIFICE PIN-LP GAS (#55 DMS)
(INTEGRAL TO THERMAL VA LVE)]
25 14026 GRIDDLE COVER HANDLE
15001-09 GRIDDLE COVER HANDLE SCREW (2)
26 16046-2 INDICATOR LIGHT LENS
GRIDDLE ASSEMBLY
