PARTS LIST:
ITEM # PART # DESCRIPTION
1 90253 GRILL COVER
2 90140 GRILL FRONT TRIM
3 12108 CAST IRON GRATE
4 90262 BRIQUETTE TRAY ASSEMBLY
5 90034 GRILL U-BURNER
6 90042 GRILL BOX ASSEMBLY
7 13073 THERMAL VALVE
8 90045-02 GRILL TUBING
9 16009-01 IGNITER
10 18165 PIPE PLUG
11 13005-48 ORIFICE HOOD-NAT. GAS (#48 DMS)
ORIFICE PIN-L.P. GAS (#55 DMS)
(INTEGRAL TO THERMAL VA LVE)
12 16001 MICROSWITCH
13 13068 SIMMER VALVE-STANDARD
14 18030 ELBOW
15 15109 BOLT / GASKET
16 90260 CAM - GRILL SWITCH
17 14006-PL BEZEL
18 14130 GRILL KNOB
19 16077 FIBERGLASS SLEEVE
20 16006 TERMINAL BLOCK
21 16075 POWER CORD - RANGES
16005 POWER CORD - COOKTOPS
22 150112 SPEED CLIP - CAM - GRILL SWITCH
23 14026 GRILL COVER HANDLE
15001-09 GRILL COVER HANDLE SCREW (2)
18
GRILL ASSEMBLY
