CHECK 1) the Electrical / Gas Supply as outlined in
the General Instr uction section.
2) Visually check for igniter breaka ge. If ignit -
er is broken, remove / replace
3) Remove Valve Panel (see General instr uc -
tions and note removal of "Red" screw behind control
knob- on some units )
4) 120 V supplied to Thermostat from the ter-
minal block ?(live= black) If not, troubleshoot power
supply lines, If YES,
5) Disconnect power, Remove live supply wire
from Thermostat & check for continuity between the
live Ther mostat terminal and the Broiler output termi-
nal w hen Thermosta t dial is rota ted to the "Broil"
position. If there is no continuity remove / replace
T hermostat.
6) If Ther mostat is OK, Remove the wires
from the Broil side of the Thermal Valve and check for
continuity between the two (2) terminals on the face of
the valve. If none, remove / replace. [Access the Dual
Ther mal Valve by r emoving the top, central section of the cooktop
(may be a Grill, Griddle, or Open Top Burner section, de pend -
ing on the model) Next, remove the ser vice access panel in the
rear to expose the Thermal Valve]
7) If the Thermal Valve is OK, Remove the
wires from the Broiler Igniter and check the igniter
leads for continuity. If none, remove / replace igniter.
8) If the Igniter is OK, Check the Live (black)
and Neutral (white) Retur n Wire for continuity to the
neutral (white) wire of the power suppl y cord. If unit
continues to not function, check all r elated wires for
continuity. - (r ef er to the schematic)
CHECK
1) the Electrical / Gas Supply as outlined in
the General Instr uction section.
2) Visually check for igniter breaka ge.
If igniter is broken, remove / replace
LARGE OVEN / BROILER TROUBLESHOOTING
WHAT TO DO: USEFUL NOTES:PROBLEM AREA:
Large Oven Broiler
will not operate
Oven will not operate
NOTE:-Ensure at
the supply source
that the live and neu-
tral wires are not
reversed ( If they are,
this would not be
covered under
warranty)
