INTRODUCTION
This service manual covers Models DCS-(RG)
(C) - (30) (36) (48) - (4) (6)-(GD) (GL) (GG)
The DCS Professional Series of Gas Ranges
was designed to provide features tailored to a cus-
tomer with high expectations. This Service Guide was
cr eated with the goal of minimizing customer incon-
venience and having any necessary r epair s done
quic kl y and correctly. If, in the course of using this
manual, you should have any difficulty, or you feel
that some important item has been omitted, please let
us know with a phone call or Fax.
T his man ual w as cr eated for use by a qualified
technician, authorized by the DCS Service
Department.
To identify the Model and Serial #, locate and
read the appliance rating plate. The rating plate is
located on the rear left side of the interior top burner
box (remove the top bur ner grates and bowls), or on
the right side of the burner box on some six bur ner
models. In general, our Model numbering logic is as
follows;
1 2 3 4
ie.
DCS-RG-484GG
1) (RG) denotes a Range with gas ovens and
an integral gas cooktop, (C) denotes a gas cooktop.
2) (48)[47 7/8], (36)[35 7/8], or (30) indica tes
unit nominal Width (in inches)
3) (4), or ( 6) indicates # of open top bur ners
4) (GG) indicates a Griddle and Char-Rock
Grill, (GD) indicates a ther mostatically controlled
Griddle section, or (G L) indicates a Char-Roc k Grill
section
Before servicing the range, it is first impor tant
to accur ately define the exact details of the complaint
and then assess the cause of the defect. Complete
Installa tion Instructions are inc luded with each a ppli-
ance and should be consulted to check for proper instal-
lation practices. Charges rela ted to Installation ar e not
cov ered under war ranty. Common for a product this
lar ge and hea vy is dama ge due to reckless handling by
tr ucking fir ms, or Installation personnel moving the
product into position.
What follows is an overview of DCS warranty
provision. Review the warranty policy to determine
what is covered under the war ranty r epair provisions
and what will not be covered. Before beginning any
work, the proposed ser vice should either be authorized
by DCS, or, in the event the work is not cover ed under
warranty, the customer be infor med of their responsibil-
ity for the repair charges.
Introduction / Warranty Introduction ...................1
Warranty Information..................................................2
Troubleshooting-General...........................................3
Orifice Hood / Pin Size Chart- L.P / Nat. Gas..3
Model Identification ................................................4-5
Outer Body Parts.......................................................6-7
Backguards .................................................................8-9
Open Top Burners Partlist.................................10-11
Troubleshooting - Leaks..........................................12
Troubleshooting - Open Top Burners ................12
Griddle Partlist ......................................................13-14
Troubleshooting - Griddle .................................15-16
Grill Partlist ............................................................17-18
Troubleshooting - Grill .......................................19-20
Large Oven / Broiler Partlist............................21-22
Troubleshooting - Oven / Broiler....................23-25
Small Oven Partlist...............................................26-27
Troubleshooting - Small Oven..........................28-29
DCS SERVICE MANUAL
1
TABLE OF CONTENTS:
