PARTS LIST:
ITEM # PART # DESCRIPTION
1 90104-01 RG 48 LANDING LEDGE
90104-02 RG 36 LANDING LEDGE
90104-03 RG 304 LANDING LEDGE
2 90100-PA RG 484GG VALVE PANEL
90100-01 RG 486GD VALVE PANEL
90100-02-PA RG 486GL VALVE PANEL
90102-PA RG 366 VALVE PANEL
90102-01-PA RG 364GD VALVE PANEL
90102-02-PA RG 364GL VALVE PANEL
90099-PA RG 304 VALVE PANEL
90101-PA C 484GG VALVE PANEL
90101-01-PA C 486GD VALVE PANEL
90101-02-PA C 486GL VALVE PANEL
90103-PA C 364GL VALVE PANEL
90103-01-PA C 364GD VALVE PANEL
90347 RGA 304 (SS) VALVE PANEL
90347-01 RGA 304 (WHITE) VALVE PANEL
90103-02-PA C 366 VALVE PANEL
3 90090-01 RG 48 RIGHT BODY PANEL
90217-01 RG 36 RIGHT BODY PANEL
90114-01 RG 304 RIGHT BODY PANEL
4 90090-02 RG 48 LEFT BODY PANEL
90217-02 RG 36 LEFT BODY PANEL
90114-02 RG 304 LEFT BODY PANEL
5 18052-02 LEVELING LEG
6 90164 RG 48 KICK PANEL ASSEMBLY
90219 RG 36 KICK PANEL ASSEMBLY
90228 RG 304 KICK PANEL ASSEMBLY
7 150034-3 HINGE RECEPTACLE
8 90186-PC 27" DOOR INSIDE LINER (RG 48/36)
90200-PC (RG 304) DOOR INSIDE LINER
9 150034-1 27" OVEN DOOR HINGE (RG 48/36)
15097 (RG 304) OVEN DOOR HINGE
10 14131 WINDOW PACK
11 90106 27" OVEN OUTSIDE DOOR PANEL (RG 48/36)
90094-02 (RG 304) OVEN OUTSIDE DOOR PANEL
11A 90184-02(27”), 90184-01(12”) OVEN DOOR ASSEMBLY
90184-03 RG 304 DOOR ASSEMBLY
12 17001 DCS LOGO -SM. (COOKTOPS)
17001-03 DCS LOGO -LG. (RANGES)
13 90187-02 27" OVEN DOOR HANDLE (RG 48/36)
90187-03 (RG 304) OVEN DOOR HANDLE
14 18164 DOOR HANDLE ENDCAP
15 90112 12" DOOR OUTSIDE PANEL
16 90187-01 12" DOOR HANDLE
17 90107 27" DOOR INSULATION RETAINER (RG 48/36)
90097 (RG 304) DOOR INSULATION RETAINER
18 90113 12" DOOR INSULATION RETAINER
19 90111-PC 12" DOOR INSIDE PANEL
20 15001-34 BOLT - DOOR HANDLE
21 15001-09 SCREW - DOOR TOP
22 90068-01-L/H, 90068-02-R/H DRIP PAN - 48"
90212-36" , 90234-30" DRIP PAN
22A 90202-02-L/H, 90202-01-R/H DRIP PAN HANDLE - 48"
90213-36" , 90208-30" DRIP PAN HANDLE
23 30313-3 DRIP PAN LINER (UNDER GRILL / GRIDDLE ONLY)
24 150034-2 12" OVEN DOOR HINGE
25 90054-01 (R), 90054-02 (L) COOKTOP 48 SIDE TRIM
90053-02 (R), 90053-01 (L) COOKTOP 36 SIDE TRIM
26 90259-01(R), 90259-02(L) RG 366 FRONT PANEL
27 90196-01-PC 27” OVEN BOTTOM
90196-02-PC 12” OVEN BOTTOM
90273-PC RG 304 OVEN BOTTOM
28 90055-01(R), 90055-02(L) C 48”, 366 only SIDE INSULATION RETAINER
90050-01(L), 90050-02(R) C 364 SIDE INSULATION RETAINER
29 90163 RG / RGA CENTER SPACER- GRATE
30 19003-1(BAKE), 19003-3(BROIL) 27” OVEN RACK
19044-01(BAKE), 19044-02(BROIL) RG / RGA 304 OVEN RACK
31 19003-02 12” OVEN RACK
7
BODY PARTS ASSEMBLY
