195
2
4
3
Complete
Rear
Lay out all four parts as shown above.
Lay the base face down on a at surface to ensure all the holes are aligned,
then secure the frame joint with four half-tightened cap bolts.
Line up the holes at each joint,
and insert a cap bolt into each.
Then use the hex wrench to further
tighten the bolts – but only lightly
at this stage to allow room for
adjustment later.
Tighten the cap bolts by hand, as far
as you can.
Painted top faces down
All parts upside down
D
C
Indent
