8
4
9
7
L
R
L
R
8
2.6x 12mm
TP Screw
14
2 x 8mm
TP Screw
Mount the retractable landing gear on main wing with
four 2.6x12mm TP screws. Then put the PVC wheel
well in place with lock with 2x8mm TP screw.
Attention: Retractable landing gear and its parts are
NOT included.
Cut away the covering on where the retractable
landing gear will be mounted.
Attention: Not do cut too deep and weaken the balsa-
wood.
Retractable Landing Gear
Retractable Landing Gear
2.6 x 12mm Screw
2 x 8mm TP Screw
Rudder
Attach rudder with C/A glue and make sure rudder can
move smoothly.
Attention: Make sure rudder is attached properly.
L
R
C.A
To Next Page
