100.6015.10 - 4 -
1 INTRODUCTION
1.1 General
The ADVANCE
®
remote meter panels are expertly engineered and carefully tested to assure years of
satisfactory operation. The meter panels are constructed of the finest materials available for gas service.
Proper installation and care will ensure the best operation. Read instructions carefully and retain for future
reference.
These instructions cover Series 200 Remote Meter panels only. Refer to the following for other components:
Remote Meter Panel Dimensions - 100.3004
Vacuum regulator -100.6010
Ejector - 122.6005
Automatic Switchover -100.6030
1.2 Warranty and Service
See 005.9001 for ADVANCE equipment warranty.
NOTE: The Series 200 Remote Meter Panel is designed for use with a Series 200 gas feeder. The ADVANCE
equipment warranty and service policy is null and void, as it pertains to user protection, if the Series 200
Remote Meter Panel is misapplied.
It is recommended that the Gas Dispensing System be inspected and serviced a minimum of once per
year.
More frequent service periods may be required due to: 1) the type, quality and quantity of the gas being
handled, 2) the complexity of the gas supply system, 3) the quality and quantity of water or process liquid
being used to operate the ejector(s), and 4) operation procedures.
More frequent service periods are especially indicated when venting of the VR is occurring during the one
year operational period. This is usually indicative of foreign debris holding the inlet valve open or destruction
of the inlet valve parts caused by the gas quality not up to industry purity standards.
1.3 Remote Meter Panel Data
Capacity Meter Tube Size
Capacities Available as Chlorine
(For Carbon Dioxide, see note)*
Tubing Connection
100 PPD
(2 kg/h)
3"
4, 10, 25, 50, 100 PPD
(75 & 200 g/h, 0.5, 1, 2 kg/h)
Inlet - 3/8", 1/2", 5/8"
Outlet - 3/8"
250 PPD
(5 kg/h)
3"
25, 50, 100, 200, 250 PPD
(0.5, 0.9, 2, 4, 5 kg/h)
Inlet - 1/2", 5/8"
Outlet - 1/2"
500 PPD
(10 kg/h)
6"
25, 50, 100, 200, 300, 500 PPD
(0.5, 0.9, 2.0, 4, 6, 10 kg/h)
Inlet - 5/8"
Outlet - 5/8"
Accuracy: 4% of maximum flowmeter capacity
* Chlorine meter tubes are used for carbon dioxide service with factor tag x 0.78.
1.4 Multiple Meter Panels
Multiple meter panels are available with up to four (4) meter. These meters are usually mounted on a panel
with a common inlet block and individual gas flowmeter outlets. The multiple meter panels are used for the
same gas only.
