5
INSTALLATION:
A. Wall Mounting
1. Taking into consideration the minimum clearance distances as indicated in the following
gure locate the heater on the wall and mark the positions of the four mounting holes
to be drilled. The heaters shall be installed at 0.5m-1.5m above the oor and 1.0m under
the ceiling.
DO NOT INSTALL THE PANEL HEATER:
• Under a xed mains power socket.
• In bathrooms.
1. Using the drill bit provided in the
accessory pack, drill the holes at the
marked positions.
2. Insert the plastic rail tting supplied
with the accessory pack into the
holes.
3. Align the four mounting holes on
the panel heater with the plastic rail
ttings and install the panel heater.
4. Screw the four fasten bolts into the
plastic rail ttings.
5. Insert the screw caps over the
fasten bolts.
6. To remove the unit from the wall,
switch off and unplug the heater.
Remove the screw caps and unscrew
the screws and remove the heater.
