Operating instructions and warnings
9
Protection level ..............................................IP 54
6 OPERATING CONDITIONS
202E control board is designed for the automation of swing gates operated by 230 V a.c. motors.
This control board has been designed and tested for operation under “normal” conditions for both
residential and industrial use.
WARNING Using the product under unusual conditions not foreseen by manufacturer may cause
dangerous situations; this is the reason why all the conditions prescribed in these instructions must be
followed.
A2
WARNING Under no circumstance must the product be used in an explosive environment or sur-
roundings that may prove corrosive and damage parts of the product.
A3
ASSEMBLY AND WIRING INSTRUCTIONS
Connect to the power supply 230 V a.c.± 10% 50 Hz through a multi pole switch or a different device
that can ensure multi pole disconnection from the power supply, with a contact opening of 3 mm. Use a
cable with a minimum section of 3 x 1,5 mm² (e.g. a H07RN-F type).
Table 1 terminal boards connection
1-2 F N
3-4
Flashing light output 230 V a.c. 50 Hz max 40W
5-6-7
Motor output max 1 X 500W (5 = opens, 6 = closes, 7 = common)
8-9-10
Motor output max 2 x 500W (8 = opens, 9 = closes, 10 = common)
11
START N.O. open/close switch.
12
FOTO
N.C. Photocell input. When activated, it reverses the movement while closing, not
active while opening.
13
COM Common inputs
14-15
Auxiliary power supply output 24 V a.c. max 400mA
16
Aerial signal
17
Aerial ground
8 USE INSTRUCTIONS
After making all correct connections to the terminal board, feed the control board and remember to short-
circuit the FOTO input, if unused, with the common (COM).
Factory settlements allow the use of standard system without any installer’s programming support. If ne-
cessary, operation parameters may be personalized.
SEL and SET switches and signalling led allow control board settlements and programming. All program-
ming functions may be done at control board ignition or after a closing cycle.
8.1 433 Mhz built in receiver
Radio control learning:
1. Press repeatedly the “SEL” key to turn the RADIO led on.
2. Press (once) the “SET” key: the RADIO led starts flashing and shows the receiver learning status.
3. Press the radio control key you want to settle. The led lights up for a second, then starts flashing (lear-
ned key).
4. For any other key or radio control, repeat step 3.
5. Wait for the led to light up (learning complete). At this point press on the “SEL” key to select any other
To Next Page
