PAR. PROCEDURE SETTABLE VALUES
PROGRAMMING PROCEDURES
Unused parameter Unused parameter Memorization of the motors’ stroke Deletion of transmitters Transmitters memorizing Search and deletion of a transmitter Restoring the operating parameters Lock access to programming How to learn connected DE@NET devices (unused at the moment) Restoring the “I/O” confi gurations (input/output) Downloading data on the external memory unit Uploading data from an external memory unit Visualisation of inputs and operations-counter status Unused parameter Unused parameter
PAR. PARAMETER DESCRIPTION SETTABLE VALUES
DEFAULT VALUES
ADVANCE ADVANCE XL
INPUTS CONFIGURATION PARAMETERS
INPUT_2 selectioning input type
• 000: IN2 type=free contact • 001: IN2 type=constant resistance 8K2
Selection of pushbutton ▲ operation
Warning: select a value between 000 and 007
• 000: NONE (unused parameter) • 001: START (start) • 002: PED. (pedestrian) • 003: OPEN (separated open) • 004: CLOSE (separated close) • 005: OPEN_PM (man present open) • 006: CLOSE_PM (man present close) • 007: ELOCK_IN (confi gurable Output 2. See P062) • 008: PHOTO 1 (photocell 1) • 009: PHOTO 2 (photocell 2) • 010: SAFETY 1 (safety rib 1) • 011: STOP (lock) • 012: FCA1 (opening limit switches Mot1) • 013: Not Available • 014: FCC1 (closing limit switches Mot1) • 015: Not Available • 016: SAFETY 2 (safety rib 2) • 017: Not Available • 018: Not Available • 019: AUX_IN (confi gurable Output 1. See P066) • 020: SAFETY INHIBITION (SAFETY inhibition)
▲
Selection of pushbutton ▼ operation ▼ INPUT_1 operating selection IN1 INPUT_2 operating selection IN2 INPUT_3 operating selection IN3 INPUT_4 operating selection IN4
