47
ADVANCE ADVANCE XL
OPERATING PARAMETERS
Unused parameter
Electric lock duration adjustment
If P062 or P066= 000|006, adjust the activation time of the LOCK output;
If P062 or P066= 007, adjust the deactivation time of the LOCK output;
0sec……………..10sec
Maintenance Operations-counter: if = 0 reset the counter and disables the intervention request , if> 0 indicates the number
of operations (x 500) to be made before the control panel executes a 4 second additional pre-fl ash to indicate the need of
maintenance.
i.g.: If P065 = 050, operations number = 50x500 = 25000 operations
Warning: Before you set a new value of the counter-manoeuvres maintenance, the same must be reset by setting P065= 0 and
only later P065 = “new value”.
• 000: “Request Maintenance disabled
• >000: “Number of operations (x 500) for required maintenance
(1...................................255)
OUTPUT_1 functioning selection:
If=1 fi xed fl ashing output (for fl ashing lights with internal intermittent circuit); If=2 intermittent fl ashing output; If=3 Fixed open
gate LED” (output always On when the gate is open, OFF at the end of a closure manoeuvre); If=4 Intermittent open gate LED”
(slow intermittent output during opening and fast during closing, always ON with gate open, always OFF only at the end of a closing
manoeuvre); If=5 Courtesy light” (output ON during every movement, OFF when the motor stops, after the delay set); If=6 24V
output for electric lock in fi xed mode; If=7 24V output for electric lock in inverted mode; If=8 output for accessories power supply;
If=9 24V output commanded by AUX_IN input in impulse mode; If=10 24V output commanded by AUX_IN input in bistable mode;
If>10 24V output commanded by AUX_IN input in timed mode (the value set indicates the switch-off delay in seconds).
Warning: If P066=8, output functioning is determined by the functioning envisioned in parameters P061 (Energy Saving) and
P071 (Safety devices autotest).
Warning: To adjust the activation/deactivation times in the 006 | 007 modes, use parameter P064.
• 001: “fi xed fl ashing output
• 002: “intermittent fl ashing output
• 003: “Fixed open gate LED
• 004: “Intermittent open gate LED
• 005: “Courtesy light (switching off delay set from P052)
• 006: “24V fi xed electric lock output max 5W
• 007: “24V inverted electric lock output max 5W
• 008: “24V accessories power supply output max 5W
• 009: “24V impulse mode output max 5W
• 010: “24V bistable mode output max 5W
• >010: “24V temporized output max 5W
(11sec………………255sec)
SAFETY 1
Operation of the SFT input: if = 0 safety edge always enabled, if = 1 safety edge enabled only while closing, if = 2
safety edge enabled only while closing and before any movement, if = 3 safety edge enabled only when opening, if
= 4 safety edge enabled only while opening and before any movement; as for the obstacle detection with internal
anti-crushing sensor, also the activation of the inputs SFT1 and SFT2 causes the complete or partial reversal as
set by P055 (duration of inversion on obstacles while opening, and P056 (duration of reversal on obstacle while
closing)
• 000: “safety edge always enabled
• 001: “safety edge enabled only while closing
• 002: “safety edge enabled only while closing and before any movement
• 003: “safety edge enabled only when opening
• 004: “safety edge enabled only while opening and before any movement
SAFETY 2
Unused parameter
Adjustment of acceleration durability
Warning: if soft start is activated, the acceleration is deactivated indipendently from P070 value.
• 000: “acceleration deactivated (it runs an acceleration of minimum durability,
almost imperceptible)
• 00X: “adjusts the acceleration durability at 1,5 sec (X*6 ms)
(1...................................255)
Safeties self-test: if = 0 24V output with autotest disabled; if = 1 24V output for safeties with self-test (it turn the output off and
check the contact opening before each maneuver).
Warning: In order to work in self-test mode, all devices must be connected to the confi gurable 24V output (7-8 for OUTPUT_1) (16-
17 for OUTPUT_2) with P062 and/or P066 = 8, and be wired and aligned before the motor stroke learning (P003).
• 000: “net power supply (safeties self-test disabled)
• 001: “safeties self-test enabled
Activation of SAS function (with NET_EXP only): SAS output is connected to an input STOP / SAS INPUT of a second control panel,
causing the operation “trap man” (disabling the opening of the second door as long as the fi rst is not completely closed).
If this parameter is enabled after a reset, it performs an automatic RESP during which the SAS output is not activated. If limit
switches are present and they are crushed after a reset, the RESP is not executed.
Warning: if both doors are manually unlocked and moved from the closed position creates the interlock condition. You will then
need to manually close at least one of the two doors.
• 000: “SAS function” deactivated
• 001: “SAS function” activated
