ADVANCE ADVANCE XL
OPERATING PARAMETERS
Forced “Hold to Run”: if this function is enabled, all inputs confi gured as OPEN and CLOSE change automatically also to OPEN
UP and CLOSE UP (hold-to-run commands) if activated and kept active in case a safety contact (photocell and/or safety edge) is
triggered. This function thus allows to control the automation even in case the safety devices are faulty. If the input is no longer
maintained active, the automation returns to automatic operation.
When using safety edges confi gured as SAFETY1 or SAFETY 2, this function is not compatible with the values 001 and 003 of
parameters P067 and P068.
For security reasons, we recommend that you DO NOT use this function in case there are any clocks/timers connected to the
inputs confi gured as OPEN or CLOSE.
• 000: function disabled
• 001: function enabled (forces switch to Hold-to-run mode when safeties are
triggered and OPEN/CLOSE commands are maintained)
Photocells inhibition: if this function is enabled, it is possible, once the position of the photocells has been detected, to disable
their action in the area between the position of the photocells and the “door-closed” position (this happens both during opening
and closing). The point where the inhibition starts is memorized by triggering of the photocells during the automatic closing phase
of the stroke learning (P003), For the inhibition to be effective, the photocells must be wired as PHOTO 1.
• 000: inhibition disabled
• 001: inhibition enabled (photocells are always ignored in the area between the
detection point and the “door-closed” position)
Unused parameter
Enable Save port position in memory at server shutdown (see RESP in screen error table).
if P076=0 at server shutdown, the port position is not saved and the position is always reset at next boot.
if P076=1 at server shutdown, the port position is saved in the memory and the position is not reset at next boot.
Warning: Perform a new motor stroke learning (P003) every time you change the parameter.
• 000: RESP active
• 001: RESP not active
Electronic positioning brake.
Caution: If active (P077=1), it is NECESSARY to set parameter P076 = 0 and install the mechanical stop (Art. AB/FM not supplied)
on the rail in the open position.
• 000: not active
• 001: active
Confi guration parameters dedicated to the expansion card NET_EXP (for a detailed description of the parameters, refer to the instruction manual).
