Deaf Bonce AP-M80SQL - Specifications

6
EN
5. SPECIFICATIONS
THIELE-SMALL PARAMETERS
Size (Inch)
Surround material
Cone material
Frame material
Magnet type
Voice coil size (Inch)
Model
Power RMS (W)
Power MAX (W)
Fs (Hz)
Vas (L)
Qts
Spl (dB)
BL
Impedance (Ohm)
AP-M80SQL
1.5
Pressed paper
Hybrid (Ferrite+Neodymium)
Cloth
150
300
8
Stamped Steel
4
95.3
80
22.42
0.41
7.44
This specified sensitivity is not directly connected with the sound pressure in the vehicle and therefore should not be
used as the sole indicator for comparison with other speakers.
Frequency response (Hz)
80 - 14 000
Voice coil wire
CCAW
LPF - 8-10 kHz (12 dB/Oct)
AP-M80SQL: HPF - 120-150 Hz (24 dB/Oct)
