10
15
Place the adjuster in the small
recess in the centre of the rear
wing, as shown in the picture. Hold the
part in place until the glue is dry.
16
At the end of this stage of the assembly, the rear wing has already begun to take
shape. Store the wings in a safe place so they can not be damaged.
12
Position the right endplate of the
rear wing endplate, as shown.
Then take the rear wing assembly, and
place it on the raised part of the end
piece.
13
Secure the endplate in place
using two 1.4 x 6mm screws.
14
Take the the rear wing adjuster
and apply superglue to the at
surface, as shown.
