9
06
Position the rear middle wing
top plate as shown, and apply
superglue to the sunken area of the part.
07
Take the back of the rear middle
wing baseplate and press it into
the sunken area of rear middle wing top
plate. Hold in place while the glue sets.
08
Place the assembly on the raised
areas on the inside of the left rear
wing endplate, as shown.
09
Hold both parts in position. Take
one of the 1.4 x 6mm screws, and
insert it into the hole of the rear wing
endplate. Tighten to secure the two parts
from Steps 07 and 08.
10
Position the rear upper wing on
the left rear wing endplate, as
shown.
11
Holding the components in this
position, turn the assembly, so
that the outer side of the endplate is
exposed. Fit a 1.4 x 6mm screw into the
hole of the rear wing end piece to secure
the parts.
