14
15
Apply glue to the top and
bottom of one of the supports.
13
Apply superglue to the two tabs
of one of the inner upper aps.
Using needle-nose pliers, position the
tabs into the two recesses underneath
the upper aps (indicated by the green
arrows and dashed lines).
16
Position the support, as shown,
between the underside of the
inner upper ap and the front wing.
Place its ends into the recesses of the
two parts (see arrows). Repeat Steps 15
and 16 for the right side.
17
At the end of this session, the front wing of your Red Bull Racing RB7 should look
like the one shown above. Store the wings until they are needed again.
14
Hold the inner upper ap in place
while the glue dries, ensuring it
dries at a right angle. Repeat the Steps
13 and 14 on the right side of the front
wing.
90°
