384
13
Turn the assembly over so that you can access the top of the chassis, then use the
screwdriver to undo and remove the ve circled screws from the gearbox cover
(the centre upper plate). Again, keep these to one side as you will need them later.
14
When you’ve removed all the
screws, carefully lift the gearbox
cover away from the chassis and put it to
one side.
11
The next step is to prepare the chassis to hold the engine. To do this, lay your RB7
chassis on your work surface with the underside facing upwards. The two screws
circled in the picture will be removed in the next step.
12
Undo the screws using a Phillips
screwdriver and keep them safely
to one side, because you will be using
them at a later stage.
