FITTING ROBI’S FACE
21 22
Line up the face with the head assembly, as shown.
The two curves on the upper ede fit aainst the edes
of the eyes.
Fit the face between the left and riht head frames so
that the screw holes on the left and riht sides of the
face line up with the correspondin holes circled in red.
24
Turn the assembly
over and repeat
Step 23 on the
left of the face.
That completes this stage of the
assembly, with the features of Robi’s
face beginning to take shape. Store it
carefully until next time.
23
Insert two of the
M2 x 4.5mm
countersunk screws
into the holes on
the riht side of the
head, indicated in
Step 22. Tihten
with the
screwdriver.
Assembled
head frame
