EC-20, EC-10 and EC-5 User’s Manual
2. About the EC-20, EC-10, EC-5
5
Sensor Features
Fig.1: EC-20 diagram Fig. 2: EC-5 diagram
Wiring Diagrams
3.5mm Plug Wiring
The EC-20, EC-10 and EC-5 come with a 3.5mm “ste-
reo plug” connector. This allows for rapid connection
directly to Decagon’s Em50 and Em5 logger and the
Circuitr y
Sensor
