DECKED MG3 - DRAWERS; Brackets + Wheels

MG3 & MG4 | V1 | Page 12
2" BOLT
CORNER
BRACKET
HELPFUL TIP: If you purchased drain
plugs, install now (instructions are
included with drain plugs).
TUBE BRACE
GOES HERE
DRAWER 1
DRAWER 2
DRAWER 1
➡
CAB
WHEELS
DRAWERS: BRACKETS + WHEELS
• Each drawer has a left and a right bracket. Bolt brackets into place via bottom two holes in bracket with 3/4"
length bolts. Use the 2" length bolt for the upper cabside wall hole in bracket; BAG DRAWER 1.
• Install a tube brace in each drawer with two 3/4" length bolts; BAG DRAWER 1, BAG DRAWER 2.
• Attach wheels onto drawer brackets with a 7/32" hex wrench; BAG WHEELS.
