DECKED MG3 - Installation Guidelines

▼ HEY! TORQUE BOY: READ BEFORE YOU INSTALL DECKED ▼
▼ ASSEMBLY OVERVIEW ▼
CENTER VERT
CABSIDE VERT
DRIVER SIDE DECK
(NARROW)
PASSENGER SIDE
DECK (WIDE)
DRIVER SIDE
AMMO CAN
PASSENGER SIDE
AMMO CAN
DRIVER SIDE
STUD "YUP"
PASSENGER SIDE
STUD "YUP"
DRIVER SIDE
AMMO CAN LID
PASSENGER SIDE
AMMO CAN LID
TORSION
BRACE
CCHANNEL
CCHANNEL
TAILGATE
1. DON'T over tighten bolts, get em' good 'ole hand-tight.
2. DON'T use power tools.
3. If you don't follow directions and do use power tools:
1). Set clutch at a very low setting.
2). Don't blow it.
3). If you blow it, see NOTE.*
NOTE* Two extra threaded inserts are included in BAG
PREP-EXTRA. That's all you get.
4). DON'T over tighten J-hooks during installation.
Make 'em good and snug enough to keep the
system from moving in the bed.
5). Do read these instructions closely.
NOTE: Most of the images in these instructions
depict the short CHEVY/GMC bed, but they apply to
both length beds.
