Tel.: +49 (0)4105 / 65 60 – 0
* DECKMA GmbH *
Fax: +49 (0)4105 / 65 60 – 25
E-mail: info@deckma-gmbh.de
*
Internet: www.deckma-gmbh.de
8. TECHNICAL DATA
Power Supply: 24V DC
Current Consumption: ca. 100mA max.
Dimensions: 144 x 72 x 125 mm (h x w x d)
Console cut-out: 138 x 66 mm (h x w)
Ingress Protection: IP 44 (at front when mounted in console)
Weight: 0.4 kg (without power supply unit)
9. TERMINAL ASSIGNMENT
Terminal JP1
1 + 24V Supply +24V DC
2 - GND Supply - GND
3 NO
Relay output only of manually given signals
potential free, (max. 1A / 30V)
4 COM
5 NC
6 NO
Relay output of a continuous signal, as long as
an automatic signal is activated.
potential free, (max. 1A /30V)
7 COM
8 NC
9 NO
Relay output of manually and automatically
given signals, potential free, (max. 1A / 30V)
10 COM
11 NC
12 +24V DC Supply for signal inputs In1-In2-In 3
13 In 1
Inputs for external activation of „General Alarm“ 14 In 2
15 In 3
16 x Must not be connected
17 x Must not be connected
18 x Must not be connected
19 x Must not be connected
20 x Must not be connected
Terminal JP2
1 NO
Relay output for unit failure
potential free, (max. 1A / 30V)
Open during failure or when supply is removed
2 COM
3 NC
