If you notice an abnormality during charging, immediately abort charging,
unplug the AC cable, and pull out the charger plug from the battery.
WARNING
(4) Indication Function (List of Lamp Indications)
The ESC3 charger has the following types of lamp indications. Normally, the green light turns ON.
The red light will turn ON or blink if there is a malfunction in the battery or the charger.
(3) Battery Protection Function
The temperature of the battery during charging significantly affects the life of the battery.
Therefore, the charger controls the charging based on the battery temperature data that is sent by
the battery management system.
• The temperature of the battery at which the charger can start charging is
between 0 and 40°C.
• The charger will abort charging when the battery temperature exceeds 45°C.
NOTE
If a malfunction is displayed on the charger
Temporarily unplug the AC cable and the charger cable, and check for
damaged insulation.
If the charger cable is damaged, a short circuit between the terminals may
damage the battery.
Before checking if the same malfunction is displayed when charging another
good battery, be sure to check the charger cable for any damages.
Do not keep the power cable and the charger cable connected during a
malfunction. The current may continue to flow abnormally, damaging the
battery or the charger. Once you have checked the blinking pattern of the
malfunction indicator lamp, unplug the power cable, and remove the charger
cable from the battery.
CAUTION
