Important
For this configuration an additional PCB (accessory AD249) is
placed on the SCB-10 PCB.
Tab.31 Installation Setup > SCB-10 > DHW 1 ( DHW layered tank ) > Parameters, counters, signals > Parameters
Code Display text Description Range Adjust
ment
CP022 Zone Function Functionality of the zone 0 = Disable
1 = Direct
2 = Mixing Circuit
3 = Swimming pool
4 = High Temperature
5 = Fan Convector
6 DHW tank
7 = Electrical DHW
8 = Time Program
9 = ProcessHeat
10 = DHW Layered
11 = DHW Internal tank
31 = DHW FWS EXT
10
Tab.32 Installation Setup > SCB-10 > AUX 1 ( Zone time program ) > Parameters, counters, signals > Parameters
Code Display text Description Range Adjust
ment
CP024 Zone Function Functionality of the zone 0 = Disable
1 = Direct
2 = Mixing Circuit
3 = Swimming pool
4 = High Temperature
5 = Fan Convector
6 = DHW tank
7 = Electrical DHW
8 = Time Program
9 = ProcessHeat
10 = DHW Layered
11 = DHW Internal tank
31 = DHW FWS EXT
8
6 Installation
7686707 - v.01 - 06092018 AMC 55
