Caution
If the tank is fitted with a Titan Active System® corrosion
protection anode, connect the anode to the inlet (+ TA on the
anode, - on the tank).
If the tank is not fitted with a corrosion protection anode, put the
simulation connector in place (delivered with the DHW sensor
(accessory))
Tab.33 Installation Setup > SCB-10 > CIRCC 1 ( Swimming pool ) > Parameters, counters, signals > Parameters
Code Display text Description Range Adjust
ment
CP023 Zone Function Functionality of the zone 0 = Disable
1 = Direct
2 = Mixing Circuit
3 = Swimming pool
4 = High Temperature
5 = Fan Convector
6 DHW tank
7 = Electrical DHW
8 = Time Program
9 = ProcessHeat
10 = DHW Layered
11 = DHW Internal tank
31 = DHW FWS EXT
3
Tab.34 Installation Setup > SCB-10 > AUX 1 ( Zone time program ) > Parameters, counters, signals > Parameters
Code Display text Description Range Adjust
ment
CP024 Zone Function Functionality of the zone 0 = Disable
1 = Direct
2 = Mixing Circuit
3 = Swimming pool
4 = High Temperature
5 = Fan Convector
6 = DHW tank
7 = Electrical DHW
8 = Time Program
9 = ProcessHeat
10 = DHW Layered
11 = DHW Internal tank
31 = DHW FWS EXT
8
6 Installation
7686707 - v.01 - 06092018 AMC 57
