Important
If refilling takes too long and the water pressure is lower than
the minimum water pressure
AP006
, warning
A02.33
will
appear.
The following warning is displayed if another refill event is
required too soon:
A02.34
. Check that there is adequate
difference between the maximum water pressure (
AP070
) and
the minimum water pressure (
AP006
).
For more information, see
CU-GH08 control unit settings, page 85
6
Installation
68
AMC
7686707 - v.01 - 06092018
67
69
Table of Contents
Default Chapter
2
Table of Contents
2
1 Safety
5
General Safety Instructions
5
Recommendations
5
Liabilities
6
Manufacturer's Liability
6
Installer's Liability
7
User's Liability
7
2 About this Manual
8
General
8
Additional Documentation
8
Symbols Used
8
Symbols Used in the Manual
8
3 Technical Specifications
9
Homologations
9
Certifications
9
Unit Categories
9
Directives
9
Factory Test
9
Technical Data
9
Dimensions and Connections
13
Electrical Diagram
14
4 Description of the Product
16
General Description
16
Operating Principle
16
Automatic Refill Device
16
Circulation Pump
16
Water Flow
17
Skeleton Diagram
18
Main Components
19
Control Panel
20
Standard Delivery
20
5 Before Installation
22
Installation Regulations
22
Choice of the Location
22
Data Plate
22
Location of the Boiler
22
Ventilation
23
6 Installation
24
General
24
Preparation
24
Installing the Mounting Frame
24
Positioning the Boiler
25
Hydraulic Connections
26
Rinsing the System
26
Water Flow
26
Connection of the Heating Circuit
26
Connection of the Water Circuit for Domestic Use
26
Connecting the Secondary Heating Circuit
27
Disconnecting the Secondary Heating Circuit
27
Connecting the Expansion Vessel
27
Connecting the Condensate Drain Pipe
28
Gas Connection
28
Air Supply/Flue Gas Outlet Connections
29
Classification
29
Requirements for Shaft for C
31
Material
32
Dimensions of Flue Gas Outlet Pipe
33
Length of the Air and Flue Gas Pipes
33
Additional Guidelines
36
Connecting the Flue Gas Outlet and Air Supply
36
Electrical Connections
37
Recommendations
37
Control Unit
37
Connecting a Pc/Laptop and Diagnostic Tools
38
Access to the Connectors
38
Connection Options for the Standard PCB
38
Access to the PCB Housing
41
Description of the SCB-10 PCB
41
Connection Diagrams PCB SCB-10
45
Symbols Used
45
Factory Configuration of Circuits
47
Boiler Settings with SCB-10 Control
47
Connection Direct Zone
49
Connection 1 Direct Zone + DHW Zone
50
Connection 1 LLH + 1 Direct Zone + DHW Zone with Electrical Heating Element
51
Connection 1 LLH + 1 Direct Zone + Mixing Zone + DHW Zone
53
Connection 1 LLH + 1 Direct Zone + Mixing Zone + DHW Zone
54
Connection 1 LLH + 1 Mixing Zone + 1 Direct Zone + Swimming Pool + DHW Zone
56
Connection 1 LLH + 3 Mixing Zones + DHW Zone
58
Connection 1 Combi-Buffer + 1 Direct Zone + 1 Mixing Zone + Solar Collectors
60
Connection 1 Combi-Buffer + 1 Direct Zone + 1 Mixing Zone + Swimming Pool + Solar Collectors
61
Connection 2 Boilers (Cascade) + LLH + 1 Direct Zone + 1 Mixing Zone + DHW Zone
63
Filling the System
65
Water Quality and Water Treatment
65
Filling the Siphon
66
Filling the System with the Automatic Refill Device
66
7 Commissioning
69
Checklist before Commissioning
69
General
69
Gas Circuit
69
Hydraulic Circuit
69
Connections for the Air and Flue Gas Pipes
69
Electrical Connections
70
Commissioning Procedure
70
Gas Settings
70
Adjusting to a Different Gas Type
70
Fan Speeds for Overpressure Applications
71
Checking/Setting Combustion
72
Basic Setting for the Gas/Air Ratio
75
Final Instructions
75
Saving the Commissioning Settings
76
8 Operation
77
Control Panel Description
77
Description of the Components
77
Description of the Home Screen
77
Description of the Main Menu
77
Definition of Zone
79
Definition of Activity
79
Use of the Control Panel
79
Accessing the Installer Level
79
Changing the Display Settings
79
Changing the Name and Symbol of a Zone
80
Changing the Name of an Activity
80
Setting the Installer Details
80
Adjusting the Heating Curve
81
Activating the Automatic (Re)Filling Unit
81
Activating the Screed Drying Program
82
Start-Up
82
Shutdown
82
Frost Protection
82
9 Settings
84
Setting the Parameters
84
List of Parameters
84
CU-GH08 Control Unit Settings
85
Setting the Maximum Heat Input for CH Operation
90
Settings SCB-10 Print
91
Setting the 0-10 Volt Input Function of SCB-10
91
Analogue Temperature Regulation (°C)
91
Configuring a DHW Tank with Two Sensors
92
Reading out Measured Values
92
List of Measured Values
92
CU-GH08 Control Unit Counters
92
CU-GH08 Control Unit Signals
93
Status and Sub-Status
96
Resetting or Restoring Settings
98
Resetting the Configuration Numbers CN1 and CN2
98
Carrying out an Auto-Detect for the CAN Matrix
99
Restoring the Commissioning Settings
99
Resetting to Factory Settings
99
10 Maintenance
100
General
100
Standard Inspection and Maintenance Operations
100
Checking the Water Pressure
100
Checking the Expansion Vessel
100
Checking the Ionisation Current
100
Checking the Draw-Off Capacity
101
Check the Flue Gas Outlet/Air Supply Connections
101
Checking the Combustion
101
Checking the Automatic Air Vent
101
Checking the Safety Valve
101
Cleaning the Siphon
102
10.2.10 Checking the Burner
103
Specific Maintenance Work
103
Opening Boiler
104
Replacing the Ionisation/Ignition Electrode
104
Cleaning the Plate Heat Exchanger
104
Cleaning the Water Filter Cartridge
106
Replacing the Three-Way Valve
107
Replacing the Non-Return Valve
108
Finalising Work
108
Replacing the Control PCB
109
Replacing the CB-03 PCB
110
10.3.10 Updating the Control Panel Firmware
110
Refilling the System
111
Refilling the System with the Automatic Refill Device
111
Activating the Automatic Refill Device (if Fitted)
112
Topping up the System (Manually)
112
11 Troubleshooting
113
Error Codes
113
Warning Codes
113
Control Unit Blocking Codes
115
Control Unit Locking Codes
117
Error Memory
120
Reading out and Clearing the Error Memory
120
12 Disposal
122
Disposal and Recycling
122
13 Spare Parts
123
General
123
Parts
124
Spare Parts List
127
14 Appendix
130
EC Declaration of Conformity
130
