DeDietrich AWHP MIT-IN iSystem User Manual

AWHP 6 MR 8 MR 11 MR 11 TR 14 MR 14 TR 16 MR 16 TR 22 TR 27 TR
Nominal
amperage - A2/
W35
(2)
A 6.1 8.2 10.7 6.2 14.5 8.3 14.6 8.4 9.7 11.8
Cooling output
(3)
kW 5.4 7.9 10.5 10.5 11.7 11.7 11.7 11.7 17.7 22.2
EER
(3)
3.80 3.99 4.68 4.68 4.43 4.43 4.43 4.43 3.8 3.8
Absorbed
electrical power
(3)
kWe 1.4 2.0 2.2 2.2 2.7 2.7 2.7 2.7 4.6 5.8
Sound pressure
(4)
dBA 36 36 40 40 41 41 41 41 45 45
Nominal water
flow (ΔT = 5K)
m
3
/h
1.04 1.47 1.88 1.88 2.34 2.34 2.67 2.67 3.8 4.6
Manometric
height available
at nominal flow
rate
mbar 618 493 393 393 282 282 213 213 - -
Nominal air flow
rate
m
3
/h
2100 3000 6000 6000 6000 6000 6000 6000 8400 8400
Power voltage of
the outdoor unit
V 230 V~ 230 V~ 230 V~ 400 V3~ 230 V~ 400 V3~ 230 V~ 400 V3~ 400 V3~ 400 V3~
Sound output
(5)
dBA 63.7 65.2 65.4 65.4 66.8 66.8 69.4 69.4 67 67
R410A refrigerant kg 2.5 3.6 5 5 5 5 5 5 7.1 7.7
Refrigeration
connection
(Liquid-Gas)
inch 1/4-1/2 3/8-5/8 3/8-5/8 3/8-5/8 3/8-5/8 3/8-5/8 3/8-5/8 3/8-5/8 3/8-3/4 or
3/8-1
1/2-3/4 or
1/2-1
Max pre-loaded
length
m 30 30 30 30 30 30 30 30 30 30
Weight (empty) -
outside unit
kg 45 75 121 135 116 130 116 130 135 141
(1) Hot mode: Outside air temperature +7 °C, Water temperature at the outlet +35 °C. Performances in line with EN 14511-2.
(2) Hot mode: Outside air temperature +2 °C, Water temperature at the outlet +35 °C. Performances in line with EN 14511-2.
(3) Cooling mode: Outside air temperature +35 °C, Water temperature at the outlet +18 °C. Performances in line with EN 14511-2
(4) 5 m from the appliance, free field.
(5) Test conducted in accordance with the standard NF EN 12102
6.1.3. Sensor characteristics
Outside sensor
Temperature in °C -20 -16 -12 -8 -4 0 4 8 12 16 20 24
Resistance in Ω 2392 2088 1811 1562 1342 1149 984 842 720 616 528 454
DHW sensor
Flow sensor
Temperature in °C 0 10 20 25 30 40 50 60 70 80 90
Resistance in Ω 32014 19691 12474 10000 8080 5372 3661 2535 1794 1290 941
6. Technical specifications AWHP MIT-IN iSystem
29
06/09/2012 - 300027618-001-01

DeDietrich AWHP MIT-IN iSystem Specifications

General

Brand	DeDietrich
Model	AWHP MIT-IN iSystem
Category	Heat Pump
Language	English
