dissipates, the conductivity will return to normal and the MPULSE 3000
®
will perform
correctly again. Always check pH levels prior to adding Muriatic Acid.
SPECIFICATIONS
Chamber:
 Interconnect Method: 2” Slip Connection with Union
 Flow Rate: 65 GPM or 250 LPM
 Max Temperature 200º F (93º C)
 Weight: 8 Lbs or 3.65 kg
 Size: 24” x 5” x 5”
 Maximum pressure: 100 PSI
Electronic Control Box:
 Input Voltage: 115/230 VAC (selectable)
 Input Current: 0.16/0.08 Amps
 Max Output Voltage: 50Vpp
 Max Output Current: 350mA RMS
 Output Frequency: 4.1 KHz ± 0.1 KHz
 Max Temperature: 140º F (60º C)
 Weight: 6 Lbs or 2.72 kg
 Size: 9” x 5” x 4”
Mechanical
 Torque - 16 in-lbs.
 Wire Range: 8 ~ 18 AWG
 Insulation Strip length - 5/16"
IMPORTANT NOTE
The mPULSE3000 does not remove calcium and due to evaporative
conditions, calcium will still be visible in SPLASH ZONES around water
features, zero edge pools and spillways the calcium will be evident unless the
water is continuously reintroduced into the main body of water which
continuously retreats the calcium. The variance of this visible calcium is
dependent upon the water in your specific area.
