- 37 -
20dB（1MHz—6GHz）
Absolute Directionality（After SOL vector calibration，calibration kit’s direction
performance is superior to the one in 48dB）
45dB（50kHz—3GHz）
35dB（3GHz—6GHz）
25dB（6GHz—6.8GHz）
Phase’s Uncertainty（Preheat 1min，operate it continuously，reflection coefficient
＞0.25，typical value）
8°（9kHz—100kHz）
2°（100kHz—1GHz）
5°（1GHz—3GHz）
8°（3GHz—6.8GHz）
Port Characteristic
VSWR of Port 2：about 1.5
VSWR of Port 1：about 2.0
Concatenate a 10dB attenuator on the input port. It can reduce VSWR within 1.2。
Frequency Stability：
±1ppm/year@25℃
Supply Voltage：
11V……32V（External Power Source）；7.2……8.4V（Battery）
105V……230V，50/60Hz（Input of the power adapter）
Battery’s Endurance Time（See Chapter 6.2）：
6 hours（Frequency spectrum, field strength, signal source）；4 hours（S21 or S11，
including insertion loss measurement）
20 hours（STOP state, display screen luminance is 10%）
Temperature and Humidity Range：
-20……65℃（External supply. In this range, battery supply time is depended on
battery temperature characteristic），When it is out of 0…45℃，recalibration is
suggested. When it’s in -40…-20℃，it can be used after preheating for 5 min (RUN
state).
Humidity Range When There is non-condensing and no-frosting
Demesion：
200×114×46mm（Length×Wide×Thickness）
Quality（Battery included）：
Net Weight：less than 1.2kg
Total Weight：about 2.0kg
Note：Expect there are other specifications，the indexes are all tested through user calibration in
these following conditions:slow mode, RBW is 1KHZ,output attenuation is 0,temperature is 25℃.
Some minority and accidental parameters, or some permanent parameters may be out of the
technical parameter range.
