3
Wiring diagram
14
7 1
8
8
4 1
5
1
1
1
2
2
3
15
+
"
50
-
25 A
P1
P2
P3
P4
P5 P6
P7 P8
P3.4
P3.2
P3.3
P3.1
P4.14
P4.7
P4.6
P4.5
P4.8
P4.9
P4.4
P4.10
P4.11
P4.12
P6
P7
P8
4 1
White/blue, lock COM
White/brown, lock NO
Green, unlock NO
Violet, unlock NC
Yellow, unlock COM
Black/white, ground output
White/orange, lock NC
Red/white, +12V output
Black, siren
Black, siren
White/green, Starter kill output
Red/black, Starter kill input
Black, ground
Red, +12V
Grey/black, light output 2
Grey/red, light output 1
Black/grey, bonnet switch
Grey, door switch 1
Grey/white, doorswitch 2
White/red, auxiliary equipment
White, luggage compartment switch
White/brown, ignition
P1.5
P1.6
P1.7
P1.8
P1.4
P1.3
P1.2
P1.1
