Volume Indication
Master Volume will be communicated with the
ve LEDs in the row of Visual Indicators LEDs.
Volume of 1% will be indicated by the leftmost
LED as dimly lit, and 100% will be indicated with
all 5 Visual Indicator LEDs fully illuminated.
Visual indicator LEDs will illuminate purple
when NIGHT MODE is active.
Mute will be indicated by the Status light.
Volume mute when Status LED is Blue and
slowly blinking.
1 2 3 4 5
Visual Indicator LEDs
NIGHT MODE - enabled
Status LED
