8
TV
HDMI
OPTICAL
AUX
BLUETOOTH
HEOS
Several source colors indicate the audio bitstream for non-streaming inputs.
PCM CONTENT DOLBY SIGNAL DTS SIGNAL
Sound Bar Indicators and Status Lights
NOTE: “TV” Input is set as HDMI OUT (eARC / ARC) by default, but the input source is congurable
by going to the “TV Input” setting in the “My Devices” menu within the HEOS App.
Visual Indicator LEDs
Status LED
Source Indication
Below is a table showing the source indicators.
