Definitive Technology Studio Advance User Manual

6
Connect to your TV (cont.)
If your TV does not have
HDMI, use Optical
All sources into your TV with 3.5mm
analog mini-jack to the sound bar
Connect the included Optical cable between the
TV and sound bar. With certain TV models you may
need to turn the internal TV speakers off or set the
sound to external speaker.
Some older TV’s have only an analog output
connection. In this scenario, the TV does all the
switching between sources and the Studio Advance is
always set to INPUT #4. A Dolby Digital or DTS digital
audio signal cannot be passed through a TV’s analog
output connection. The best audio signal quality that
can be reproduced using this method is two-channel
stereo audio. This method is the least-preferred
connection method of the four described here.
Cable
Blu-ray
TV
OPT
OUT
HDMI IN
INPUTS
FIRMWARE
AUX IN
OPT IN
POWER
Cable
Blu-ray
TV
AUX
OUT
HDMI IN
INPUTS
FIRMWARE
AUX IN
OPT IN
POWER

Definitive Technology Studio Advance Specifications

General

Color	black
Subwoofer	included
Surround Sound	dolby digital, dts
Number of Drivers	6
Tweeters	3
Inputs	hdmi, toslink optical, 3.5mm audio
Outputs	hdmi
HDMI Inputs	3
HDMI Outputs	1
USB Ports	0
Bluetooth	yes
Wireless Connectivity	bluetooth
Optical Audio Inputs	1
Remote Control	yes
Smart Features	google assistant

Weight and Dimensions

Depth	4 inches
Height	3.4 inches
Width	43 inches
Net Weight	36.8 pounds
Subwoofer Depth	12.7 inches
Subwoofer Height	14.8 inches
Subwoofer Width	12.5 inches
Subwoofer Weight	11.9 pounds
