STAINLESS
HOOD
The manufacturer strives for
continuous improvements. For
this reason, the text and
illustrations in this book are
subject to change without notice.
Part Number 064 782
Installation
CAUTION
The exhaust air from the chimney hood must not be discharged into a flue or chimney
which is used for exhausting the fumes from other appliances burning gas or fuels.
Please ensure that the regulations concerning the discharge of exhaust air have been
fulfilled. ( SABS IE C60335-2-31)
S L I M L I N E
113
MIN 650
FOR ELECTRIC HOB
MIN 750
FOR GAS HOB
TOP CHIMNEY
FIXING BRACKET
KEYHOLE
SLOTS
RETAINER
HOLES
OUTLET VENT SLOTS IN
LOWER CHIMNEY
Y-PIECE FOR
RECIRCULATED AIR
SPIGOT FOR
OUTSIDE VENTING
FLANGE
Installation
Please read these instructions carefully before installing and attempting to operate the appliance.
CAUTION
The exhaust air from the chimney hood must not be discharged into a flue or chimney which is
used for exhausting the fumes from other appliances burning gas or fuels.
Please ensure that the regulations concerning the discharge of exhaust air have been fulfilled.
( SABS IE C60335-2-31)
S L I M L I N E
113
MIN 650
FOR ELECTRIC HOB
MIN 750
FOR GAS HOB
TOP CHIMNEY
FIXING BRACKET
KEYHOLE
SLOTS
RETAINER
HOLES
OUTLET VENT SLOTS IN
LOWER CHIMNEY
Y-PIECE FOR
RECIRCULATED AIR
SPIGOT FOR
OUTSIDE VENTING
FLANGE
