Required Tools (not supplied)
1. Adjustable wrench or a
socket wrench with a 8 mm
socket.
Approximate assembly time is
5 minutes.
Supplied with your generator:
1. Two(2) foot assemblies with
two (2) 8 mm nuts.
2. Two (2) wheel axle assem-
blies.
Heavy Duty Power Equipment
Wheel Kit Assembly
Commissioning the Battery
WARNING
Lead acid storage batteries contain sulfuric acid which
can cause serious injuries. The battery also gives off
explosive gases. Keep sparks, flames and cigarettes
away. Provide adequate ventilation when charging or
using batteries. Battery posts, terminals and related
accessories contain lead and lead compounds. Avoid
spills of electrolyte and wash hands thoroughly after
handling.
Use gloves and safety glasses when handling and in-
stalling lead acid batteries.
If you get electrolyte in your eyes, flush your eyes with
clean water for 15 minutes and seek medical attention.
Keep out of reach of children.
Battery Maintenance:
Routine maintenance is essential to keep the battery in good
condition and maximize its service life.
1. Keep the terminals and connections free from corrosion
and coat with petroleum jelly or grease to reduce corrosion
from occurring.
2. If the generator sits idle for more than two (2) months, it is
best to recharge the battery to ensure it is fully charged
when you need it and to increase battery life.
The battery is an optional feature. The battery is used
to start a generator equipped with an electric starter.
Not all generators are sold with batteries. Please ver-
ify with your retailer if you believe the battery is miss-
ing.
FOR YOUR SAFETY AND CONVENIENCE, THE
BATTERY WAS SHIPPED SEALED AND
PRE-CHARGED.
The battery is ready to be connected to the generator.
To connect the battery, use an adjustable wrench or 8
mm socket to secure the black wire to the black termi-
nal and the red wire to the red terminal.
Pre-assembled wheel /
axle assembly.
Two pre-assembled, retractable, handle bars,
one on each side of the generator frame.
Twist to lock / unlock. Pull or push to ex-
tend / retract.
Insert each axle and tighten
the bolt to secure in place
using an adjustable wrench
or 8 mm socket.
Insert each foot assembly
through holes in the frame.
Tighten nut with adjustable
wrench or 8 mm socket.
Step
1
Step
2
Note: A spark arrestor was supplied with your generator and must be installed for use within the State of California. See supplemental instructions.
3850, 4000, 4550 Pro, 5000(EL), 5650(EL),
6500(EL), 7500EL, 180W(EL)
