7.Hang the Glass Door (7) installed with rollers, handles and strip to the Upper Guide Rail (4). Slide the
Guide Block (14) to the bottom of the glass door. Mark down the predrilled position of the guide block.
Set the glass door aside. Now drill the hole with drill bit to the threshold. Put the silicone to the hole and
then put the wall anchor (15) into the hole. Now secure the guide block to the threshold with Screw
M4X30 (13).
17
14
17
17
17
13
14
14
7
a.
c.
e.
b.
d.
f.
Screw M4X30
9
a.
b.
a.
b.
1
14
8
Moving glass
Statinary glass
Waterproof strip
Sealing strip
Bottom guide block
O
u
t
e
r
side
Inner sid
e
8. Hang the Glass Door (7) back to the Upper Guide Rail (4) , slide the bottom of the glass door into
the slot of the Guide Block (14) . Be careful that the glass door should not touch the metal part of the
guide block.
9. Slide the Side Anti-Water Strip (8) to the Stationary Glass (17) , remove the flapper that nterferes
with the Upper Guide Rail (4)
10
