Starting System
90-864260200 AUGUST 2009 Page 4A-3
Delco PG260G1 starter specifications
No load test
Delco ID
number
Engine
rotation
Volts Minimum amp draw
Maximum
amp draw
Minimum RPM Maximum RPM
9000884 LH 12.0 35 85 2550 4150
Delco PG260L starter specifications
No load test
Delco ID
number
Engine
rotation
Volts Minimum amp draw
Maximum
amp draw
Minimum RPM Maximum RPM
9000888 LH 12.0 35 85 2550 4150
Torque Specifications
PG260F1 and PG260L
Description Nm lb–in. lb–ft
Starter mounting bolts 40.5 – 30
Battery terminal nut 9 84 –
Switch terminal nut 2 20 –
Resistor terminal nut 2 20 –
Lubricants, Sealants, and Adhesives
Tube Ref No. Description Where Used Part No.
25
Liquid Neoprene Electrical terminals 92- 25711 3
Special Tools
DMT 2004 Digital Multimeter 91‑892647A01
Positive Current Flow
NOTE: Ensure that all connections are tight and have the required resistance.
Positive current flow following ignition switch activation includes:
• Battery to the starter mounted solenoid switch (RED battery cable).
• Solenoid switch to the circuit breaker (RED).
• Circuit breaker to the wire junction (RED/PUR).
• Wire junction to the wiring harness plug (RED/PUR) terminal 6.
• Wiring harness plug to the 20 amp fuse (RED/PUR).
• 20 amp fuse to the ignition switch terminal I (RED/PUR); ignition switch is in the "START" position.
• Ignition switch terminal I to terminal C.
• Ignition switch terminal C to the neutral start switch (YEL/RED); the neutral start switch much be in the neutral position.
• Neutral start switch to the wiring harness plug terminal 7 (YEL/RED).
• Wiring harness plug to the starter solenoid (small terminal) (YEL/RED). The black (small terminal) wire is ground.
• Starter solenoid is now closed, completing the circuit between the large terminal (RED/PUR) and the other large terminal
(YEL/RED), causing the starter motor to crank.
Lubricants, Sealants, Adhesives
Tube Ref No.
Description Where Used Part No.
25
Liquid Neoprene
Electrical terminals
Electrical connections
92- 25711 3
