Delem
V0802, 5.20
Parameter 15: Decimal point pos.
Range : 0 - 3
Default : 0
Units : -
Function
Decimal point position of auxiliary axis value.
Description
This parameter defines the resolution (digits after the decimal point) in which the auxiliary axis
values are programmed and displayed on the control.
0 = no resolution, value in mm
1 = 0.1 mm units
2 = 0.01 mm units
3 = 0.001 mm units
Press the key to select the required setting.
