Delem
V1101, 3.3
Parameter 3: Y-min
Range : 0.00-9999.99
Default : 10.00
Units : mm
Function
Minimal Y-axis value
Description
The minimum position the beam can be moved to. This value is used as a soft limit. When the
start button on the control is pressed the control checks all Y-axis parameters, which are
programmed or computed. If a programmed or computed Y-axis value is smaller than Y-min the
value is limited at the Y-min value and the following error message appears on the screen.
** Y-axis << limit **
There are the following causes possible for this error message:
- programmed or computed bending position < Y-min
- programmed or computed mute point < Y-min
- computed clamping point < Y-min
Note
Make sure that the beam can reach this minimum value for the Y-axis. For example, when the
beam is in the mechanical top dead centre and the Y-axis value is 5 mm, Y-min must be bigger
than 5 mm.
