Part Number: 9295093 12/18 15
Section 2 Installation
Heavy Duty Cutting Board Bracket Mounting
Supplies Needed
• #3 Phillips Screwdriver
Parts Included For 27” & 32” Units
Qty Description Part No.
1 Left Bracket Varies
1 Right Bracket Varies
1 Silicone 9291311
2 Screw, pan head 9321519
2 Screw, flat head 9324092
2 Fender Washer 9324043
Parts Included For 48” Units
Qty Description Part No.
1 Left Bracket Varies
1 Center Bracket Varies
1 Right Bracket Varies
1 Silicone 9291311
3 Screw, pan head 9321519
3 Screw, flat head 9324092
3 Fender Washer 9324043
Parts Included For 60”, 64” & 72” Units
Qty Description Part No.
1 Left Bracket Varies
2 Center Bracket Varies
1 Right Bracket Varies
1 Silicone 9291311
4 Screw, pan head 9321519
4 Screw, flat head 9324092
4 Fender Washer 9324043
Left Bracket
Center Bracket
Right Bracket
To Next Page
