USER MANUAL AND INSTALLATION GUIDE
Use the technical description of the garage opener motor for the correct wiring.
You must nd and use the connection ports for the wall switch responsible for opening/closing the garage
door and use them during the wiring.
2. Attach the controller to the top and side of the motor using the self-adhesive tape. Make sure that the
moving parts of the gate do not come into contact with the controller or its cables!
3. Guide the sensor cable of the opening sensor in the middle, past the rack to the door. For fastening, use
the cable guide, cable fasteners and cable ties included in the package. The cable must be placed in such a
way that it cannot be accidentally damaged by mechanical damage. Place the opening sensor in the upper
part of the garage door in the middle. Before sticking the sensor, test that the device detects opening and
closing. (You can see the status of the door in the application). The appropriate distance between the two
units is 3-15 mm.
When closed, stick it with the suitable side to the garage door and the console, then fasten it with a screw. If
necessary, use the included angle irons for fastening. The cabled sensor part should be placed on the console,
on the wall, while the cableless, magnetic unit should be placed on the garage door.
FACTORY RESET:
Press the RESET button on the side of the device for 5-6 seconds to restore the factory settings.
CLEANING:
Wipe o any dirt with a soft, dry microber cloth. Do not use a wet cloth!
DISPOSAL:
This symbol on the product or on its packaging indicates that this electrical and electronic product must not
be disposed of with your other household waste. For proper disposal and reuse, please return this product
to a designated collection point. By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health, which could otherwise be caused
by inappropriate waste handling of this product. Contact your local authorities or the nearest collection point
for more details on disposal.
EN
7
